Semi Automatic Carton Sealer

S26 represents the semi-automatic machine with manual adjustment designed for king size boxes. Easy to use and simple to adjust, this machine enables to start the production in few minutes time.

Thanks to the top and bottom drive belts and the K12R or K11R taping units, they allow the perfect sealing of the box.

The strong dual mast structure with A-frame of the S26 is ready to process big size cartons, always keeping the high level of reliability of SIAT machinery.

S8 model are semi-automatic sealing machines with manual adjustment. Easy to use and simple to adjust, they enable to start the production in just minutes. Thanks to the side drive belts and the K11R or K12R taping units, they allow the perfect sealing of the box. The machines have been designed in compliance with CE regulations.

SK1 model are semi-automatic sealing machines with manual adjustment. Easy to use and simple to adjust, they enable to start the production in just minutes. Thanks to the side drive belts and the K11R or K12R taping units, they allow the perfect sealing of the box. The machines have been designed in compliance with CE regulations.

The case sealer SK20 represents the perfect solution for your semi-automatic packaging line.

The concept, with the double top and bottom drive belts, allows the control of the carton box also during the incoming process before sealing.

Thanks to the robust dual masts frame and to the primary level of the machine components, the historical reliability of SIAT machines is fully guaranteed.

The easy plug & play mode and the fast-removable taping head help the customer to save time efficiently during set-up and maintenance operations.

The semi-automatic case sealer SR20 represents the ideal solution when your packaging line processes boxes with different dimension. Thanks to the 4 belts box control, the sealing process is always guaranteed without jams, also in case of overstuffed and empty boxes. The pneumatic system allows a fast adaptation to a large range of box dimensions.

The robust dual masts frame and the branded components make the SR20 ready for round-theclock applications. The historical SIAT machines reliability is always guaranteed! The fast-removable taping head, the easy access to the motors and the clear cable management allow an efficient check of the machine, facilitating maintenance operations.

SR46 is a semi-automatic sealing machine with random adjustment. The machine consists of a metal structure painted with epossidic paint and columns in aluminium. The sliding plan of boxes is made up of galvanized rolls and stainless steel plate.

Working Cycle: the operator folds the top flaps and moves box forward in the machine until it is taken away by drive belts. The case sealer adjusts itself according to the box size and proceeds with the top and bottom sealing. The machine has been designed in compliance with CE regulations.

XL35 is a semi-automatic sealing machine with manual adjustment. Easy to use and simple to adjust, it allows the perfect sealing of the top and bottom of boxes with adhesive tape. The side drive belts are provided with a self-centering screw adjustment device.

XL35 model has been designed in compliance with CE regulations.

XL46 (large boxes) is a semi-automatic “Random” case sealer: it means that the machine is able to adjust itself on the various box sizes. The machine applies automatically two self-adhesive tape stripes on the upper and lower boxes middle line. The adjustment and use are intuitive, simple and fast.

Key Features:

• Automatic adjustment on different box sizes
• Side lower drive belts (2 x 75 mm width each)
• Drive belts speed 20 m/min.
• 2 x Motors kW 0,13 each
• 2 x K12R taping unit - 75 mm width
• Extruded aluminium telescopic legs with millimetric guide
• Locked stop emergency button
• On/Off magneto-thermic switch
• Adjustable descending height stopper of the top taping unit to increase speed rate
• Top head pneumatic pressure regulators
• Safety protections with switches to disconnect electric & pneumatic circuits if opened
• Adjustable working height 445 - 705 mm

XL461 is a semi-automatic sealing machines with random adjustment.

It means that these machines are able to adjust themselves on the different box dimensions. The machines are designed to apply automatically a “C” strip of adhesive tape of the top and bottom of boxes.

Machines adjustments and use are intuitive, simple and fast.

On the XL461 version the rest position of the top taping unit is UP: thanks to some particular devices the feeding of boxes is performed automatically.

Key Features ;

• Automatic adjustment on different box sizes
• Side lower drive belts (2 x 75 mm width each)
• Drive belts speed 20 m/min.
• 2 x Motors kW 0,13 each
• 2 x K12R taping unit - 75 mm width
• Extruded aluminium telescopic legs with millimetric guide
• Locked stop emergency button
• On/Off magneto-thermic switch
• Adjustable descending height stopper of the top taping unit to increase speed rate
• Top head pneumatic pressure regulators
• Safety protections with switches to disconnect electric & pneumatic circuits if opened
• Adjustable working height 445 - 705 mm
