Flexographic Printer

The L36-150 TC-CE model is a semi-automatic flexographic printing press for the 3-colour printing of adhesive tape, the tape cutting and rewinding in preset widths and lengths. Working cycle: the machine unwinds, Corona treats, prints, cuts and rewinds the tape; it slows down and turns automatically the rewind turrets when the preset length is reached.

Capable to print: PVC, OPP, ADHESIVE PAPER (Pre-Treated, Solvent, Hot-Melt, Acrylic Water & Solvent Basis) and gummed paper.

With an optional device, the machine can also print not adhesive material (not adhesive paper, not adhesive OPP, aluminium and reinforced paper).

Advantages

• printing stations with quick adjustment


• Exhausting suction system


• Felt roller to clean the back side of tape


• Pneumatic pumps for primer and release


• Primer and release stations

Key features

• 3 colors


• 3″ mechanical unwind mandrel with dry clutch


• Tefloned central impression drum (standard) or ceramic central impression drum (on demand)


• Width and length roll 150 mm – max. diameter 420 mm


• Slitting device by razor blades


• Set of spacers for slitting blade holders setting: 12 mm – 15 mm – 19 mm – 25 mm – 30 mm – 38 mm


• Corona treatment


• 3 hot air drying tunnels with electric resistors


• Speed control and adjustment from 0 to 160 m/min by inverter


• Anti-accident protection preset for the exhaustion of solvents


• Ventilation system (3 motor fans)


• Exhaust system (5 suction fans)


• Printed tape rewinding on change-over turrets


• Primer station


• Release station

Options

• ACL50 to print on the adhesive side of transparent tape


• Coating station to apply primer and release coats


• Peristaltic pumps for ink trays for the automatic feeding of the ink


• Pneumatic unwind roller


• Machine available without Corona Treatment


• Slitting device with pneumatic score knives for cutting reinforced tape, filament tape or masking tape
